Reversing Rear View CCD Camera Cam for Subaru FORESTER IMPREZA Outback 2010 onwards
Item Number: KIT-23SU1
Sold Out
Latest Reversing Rear View CCD Camera Cam for Subaru FORESTER IMPREZA Outback 2010 onwards is available at digoptions.com
Have Questions? Contact Us Here
***Out Of Stock***
Short description
DIG Options has become the "Installer's Choice" for car audio equipment. We listen to our customers so that they keep listening with us. DIG Options provide the automotive electronics, dash kits, cables, adapters and more so you can keep your vehicle updated with the latest technology.
Cameras from DIG Options are vigorously tested in harsh Australian conditions and backed for an Australia 12 month warranty.
Description
This listing includes 2 parts which are:
- A Premium Universal CCD Camera with 5m Video Cable and Integrated Trigger Wire
- Vehicle Specific Special Fit Camera Mount
About the Camera
170° (vertical viewing angle) High Resolution Mini CCD Reversing Park Camera
- High Resolution Colour CCD Image Sensor with crisp colour display and the latest sensor technology for improved visibility
- Best-in-Class PAL 704x576 pixel Resolution
- Special trouble-free micro 4-pin connector means you donât need to drill huge holes and it makes the install easier
- High Water/Dust Proof Rating
- Distance guidelines are built into the camera to offer approximate distance grid lines which range from safe to STOP THE CAR!
- The 170 degree viewing range with advanced CCD Image Sensor provides the latest technology in reverse cameras.
- Due to the cameras low light properties it works brilliantly at night using the light generated from your reverse lights and the camera is water resistant.
- The camera features an RCA plug for connection into your monitor video input as well as built in trigger line which means you won't need to run a separate wire for the reverse power trigger input.
Vehicle Compatibility
This part is suitable for the following vehicles. Please note that due to this being an aftermarket accessory, some minor work may be required however, you will end up with a good result.
Subaru Forester 2003 - 2010 onwards
Subaru Impreza 2007 â 2010 onwards
Subaru Tribeca 2003 - 2007 onwards
Looking for a Premium Navigation DVD Bluetooth IN-DASH System? Checkout our store categories for a suitable solution or contact us.
Other Accessories for your Vehicle are in our store including:
- Plug and Play Premium Integrated Navigation DVD Bluetooth System
- Fascia Stereo Surround
- Premium Reverse Camera
- In-Car Entertainment Monitors
- Dash Removal Tools
- Tyre Pressure Monitor Systems
- Off Road Navigation Software
- Home Electronics and much more
Camera Specifications
|
CCD |
IMAGE DEVICE |
SHARP 1/4" CCD |
SYSTEM |
PAL |
EFFECTIVE PIXELS |
512 X 582 PIXELS |
SENSING AREA |
3.6MM X 2.7MM |
SCANNING SYSTEM |
2:1 INTERLACE |
SYNC SYSTEM |
INTERNAL |
RESOLUTION |
420 TV LINES |
HORIZONTAL FREQ |
17.734 |
VERTICAL FREQ |
60HZ |
MIN ILLUMINATION |
1.0LUX / F2.0 |
VIDEO OUTPUT |
1.0V 75 Ohm |
GAMMA CONSUMPTION |
0.45 |
AGC |
AUTO |
S/N RATIO |
BETTER THAN 48DB |
WHITE BALANCE |
AUTO |
ELECTRONIC SHUTTER |
1/10,000 SECOND |
BLC |
AUTO |
CURRENT CONSUMPTION |
120mA |
POWER SUPPLY |
12v |
OPERATING TEMP |
-20C - 70C RH95%MAX |
STORAGE TEMP |
-40C - 85C RH95% MAX |
LENS |
f=2.1 / F=2.0 |
LENS ANGLE |
170 DEGREES (Vertically) |
SKU | KIT-23SU1 |
Barcode # | 9357423016165 |
Brand | Masten |
Shipping Weight | 0.2500kg |
Shipping Width | 0.130m |
Shipping Height | 0.070m |
Shipping Length | 0.035m |
Assembled Width | 0.130m |
