TR-One Fully Adjustable Direct Fit Wheel Mount for Simucube, VRS, Accuforce, OSW, Mige etc

About the TR One Wheel Mounting System

The TR One Wheel System is a Future Proof Wheel Mounting System that allows you to upgrade by replacing only a part of the mount depending on what wheelbase you mount. The base structure is made of thick-walled extruded aluminium and the plates are meticulously crafted from high-quality aluminium then anodized.

The design of the aluminium plates allows for angle and distance adjustment. The base kit (Part Number: TR80-NWMA) consists of 2 x High-Quality 80x40mm Aluminium Profiles and 4 Bed Anodised Aluminium Plates. Optional wheel mounts include a wheel deck and direct-drive front mounting plate - but this list will expand as more wheelbase brands become available. The plates themselves are extremely rigid and have a lot of adjustment for angle and forward/backwards fine-tuning - to get a perfect position!

Angle Adjustment: Fully Adjustable Mount with up to 12° degree tilt angle PLUS greater angle adjustments of the outer plates

Material: Anodised Black Aluminium Plates, Extruded Aluminium Profile, and Carbon Steel

Rig Compatibility: This part is compatible with Trak Racer Extruded Aluminium Rigs and other DIY Builds.

Not Compatible with Trak Racer TR80-LITE due to the wheel uprights only being 660mm/26" tall (compared to 780mm/30.7" on the TR80, TR120, and TR160).

Full Mount Width (including 120 x 40mm profile): 580mm/22.83"

Compatible Wheel Bases:

• Simucube SC1 / SC2 Sport, Pro, Ultimate
• VRS Force Pro
• AccuForce V1/V2 (turn the top cover around to fit)
• MiGe 130ST(small and big)
• Bodnar 53 series
• SIMAGIC ALPHA / ALPHA Mini
• Lenze MCS12 series
• Kollmorgen AKM 52-53-54 (OSW and Leo Bodnar Simsteering systems)
• Ricmotech Mini-Mite Direct-Drive Steering System Base
• Fanatec Podium DD1/DD2, DD PRO and CSL DD (by removing the center mount)

Contact us if your wheel is not listed

5 Year Warranty
